Advice
joint search for an optimal drive concept- Discussion of design features of cam drives
joint search for an optimal drive concept
interpretation
- Movement design on your working organ
- Selection of movement functions depending on your requirements (harmonious movements, low vibration, noise-optimized, etc.)
- Collision control of multiple movements
calculation
- Determination of the main dimensions
- Checking geometric feasibility
- Input and output loads from masses and forces
- Selection of the roller depending on the required service life
- Documentation of the calculation for your records
- Coordinates of the roller/curve track for your production
- Production-ready drawing for our production
optimization
- Review and recalculation of motion sequences and cam mechanisms to increase the performance of existing systems
Experience
- Since around 1970, computer-aided motion design and development of curves
- Motion design and curve solutions in a wide range of industries
Movement functions
- According to VDI guideline 2143
- In-house developments based on VDI 2143
- In-house developments for low-vibration movement
- Spline functions
software
- In-house developments by our curve specialists with continuous development
- Adaptation to new curve requirements
- Connection to CAD with output of curve profiles to CAD standard formats
